Orion HCCA121SPLX – 12 Inch Dual 1 Ohm Extreme SPL Best Powered Subwoofer | 7500W RMS Bass Power

Extreme SPLX 12 Inch Subwoofer Built for No-Compromise Output | Best Powered Subwoofer

The Orion HCCA121SPLX represents the most extreme level of bass performance in the HCCA lineup. Specifically, this 12 inch dual 1 ohm SPLX competition subwoofer is engineered for brutal sound pressure levels. As a result, it delivers overwhelming low-frequency output for the most demanding SPL builds. With 7500W RMS and 30000W peak power, it is built for competitors who push systems far beyond normal limits.

Additionally, the dual 1-ohm voice coil configuration allows ultra-low impedance wiring. Because of this, the subwoofer pairs perfectly with high-voltage, competition-grade amplifiers. Therefore, the HCCA121SPLX is ideal for extreme SPL competition vehicles, demo monsters, and record-focused bass builds.

Built for Extreme SPLX Abuse

To survive extreme power, the HCCA121SPLX uses a moisture- and UV-resistant glass fiber paper cone. Moreover, it features a reinforced NBR foam surround designed to handle violent cone movement. Together, these components maintain control during massive excursion.

At its core, the subwoofer uses a huge 4-inch high-temperature voice coil. As a result, it manages intense heat during long competition runs. In addition, a 690 oz triple-stack ceramic magnet motor structure delivers enormous motor force. This design maximizes output efficiency while maintaining control at extreme power levels. Best Powered Subwoofer for deep bass and powerful car audio performance

Ideal For

• Extreme SPLX competition vehicles
• Record-focused SPL builds
• Multi-subwoofer bass walls
• High-voltage, ultra-high-power audio systems

Key Features

• 12 inch dual 1 ohm extreme SPL subwoofer
• 7500W RMS / 30000W peak power handling
• Massive 4” high-temperature voice coil
• Glass fiber reinforced paper cone for extreme strength
• Reinforced NBR foam surround for violent excursion
• Polypropylene dustcap for added cone stability
• Huge 690 oz triple-stack ceramic magnet
• Designed specifically for SPLX-level output
• Optimized for extreme competition-style enclosures
• Legendary Orion Car Audio HCCA SPLX Series engineering

• Extreme Competition Power:  The ORION SPLX Subwoofer delivers unmatched performance with a powerful RMS handling of 7,500 watts and an astounding peak power capacity of 30,000 watts.
• Dual 1-ohm Configuration: With its dual 1-ohm voice coil configuration, the ORION SPLX Subwoofer provides flexible wiring options for optimal impedance matching and maximum power delivery.
• Precision Sound Reproduction: The non-pressed paper cone and NBR rubber surround of the ORION SPLX Subwoofer ensure accurate sound reproduction, delivering exceptional clarity even at extreme power levels.
• Exceptional Performance: Equipped with a 4-inch voice coil, the ORION SPLX Subwoofer is engineered to perform flawlessly under the most demanding audio conditions, making it the perfect choice for competitive setups.
• High-Quality Components: The ORION SPLX Subwoofer is built with a premium magnet structure, advanced cooling system, and robust materials to deliver reliable, consistent performance even during extended use.

• Subwoofer Size: 12" (Inches)
• Voice Coil Configuration: Dual 1-ohm
• Power Handling (Peak): 30000 Watts
• Power Handling (RMS): 7500 Watts
• Sensitivity: 83.24 dB
• Frequency Response: 20 Hz - 200 Hz
• Voice Coil Diameter: 4" (Inches)
• Dustcap Material: Polypropylene
• Cone Material: Moisture and UV Resistant Glass Fiber Paper Cone
• Surround Material: NBR Foam
• Magnet Information: 690 Oz Triple Stack Ceramic
• Mounting Depth: 346.5mm / 13.64 (Inches)
• Cutout Diameter: 292mm / 11.5 (Inches)
• Overall Diameter: 326.1mm / 12.84 (Inches)
